Advantech Managed Modular Media Converter, 1000Mbps, Single mode 131nm, 10km, SC (IMC-770-SM)
- Variety of choices: multi-mode, single-mode or single-strand including SFP form factor
- The modular, hot-swappable architecture reduces operational costs associated with product installation, upgrades, and maintenance
- SNMP manageable
- Supports configuration control
- Supports Link Fault Pass Through (LFPT)
Deskripsi
| Category | Attribute | Value |
| Environment | Humidity (Operating Range) | 5~95% (non-condensing) |
| Environment | Temperature (Operating Range) | 0 ~ 50 °C (32 ~ 122°F) |
| Environment | Temperature (Storage Range) | -25 ~ 70°C (-13 ~ 158°F) |
| Mechanism | Dimensions (W x H x D) | 2.0 x 10.74 x 7.05 cm (0.78 x 4.19 x 2.75 in.) |
| Mechanism | Number of Slot | 0 |
| Mechanism | Weight | 0.11 kg (0.24 lbs) |
| Ethernet Communication | Coaxial Port Number | 0 |
| Ethernet Communication | Fiber Port Connector Type | SC Type |
| Ethernet Communication | Fiber Port Number | 1 |
| Ethernet Communication | Fiber Port Optical Mode | Single-Mode |
| Ethernet Communication | Fiber Transmission Distance | 10 km |
| Ethernet Communication | Fiber Transmission Speed | 10/100/1000 Mbps |
| Ethernet Communication | Fiber Transmission Wavelength | 1310 nm |
| Ethernet Communication | RJ-45 Port Number | 1 |
| Certification | EMC | CE, FCC Class B |
| PoE Information | PoE Port Number | 0 |
Informasi Tambahan
| Brand |
Advantech |
|---|
