Advantech SmartStart, NAM, 1x ETH, 1x RS232, Plastic (BB-SL30200110-XSWH)
- LTE cat.1, 3G/HSPA+, NAM, 2x SIM
- LTE B2, B4, B5, B12, B13
- Powerful CPU and Memory, Hosting of SW IoT applications
- Wall or DIN rail mounting, Sleep mode
- 1x ETH
- 1x RS232
- I/O 1x DI + 1x DO
- Operating temp. –40 °C to +75 °C, Power supply 9 to 36 V DC
- Advanced networking, Diagnostics, VPN support, Firewall
Deskripsi
| Category | Attribute | Value |
| General | 3G/HSPA+ | Yes |
| General | Ethernet Port Count | 1 |
| General | LTE cat.1 | Yes |
| General | Number of SIMs | 2 |
| General | Region | NAM |
| General | Technology | Wireless |
| Power | Power Input (DC) | 9 ~ 36 VDC |
| Power | Sleep Mode | Yes |
| Interface | ETH Port(s) | 1 |
| Interface | I/O | 1 x DI + 1 x DO |
| Interface | RS232 | 1 |
| Environment | Humidity (Operating Range) | 0~95% |
| Environment | Temperature (Operating Range) | -40 ~ 75°C (-40 ~ 167°F) |
| Mechanism | Dimensions (W x H x D) | 150 x 30 x 87 mm |
| Mechanism | Enclosure (Plastic) | Yes |
| Mechanism | Mounting (DIN-rail) | Yes |
| Mechanism | Mounting (Wall) | Yes |
| Warranty | Warranty Period | 3 years |
| Region | NAM/LATAM | Yes |
| Cellular Communication | LTE Bands | LTE B2, B4, B5, B12, B13 |
| Cellular Communication | Number of SIM Slots | 2 |
| Cellular Communication | UMTS Bands | B2 (1900), B5 (850) |
| Antenna Connectors | Cellular Antennas | 2 x SMA |
| Packaging | Accessories | Without accessories |
Informasi Tambahan
| Brand |
Advantech |
|---|
